Double Doors Distribution Board

Get a Price/Quote

MOQ : 100 Pieces

Double Doors Distribution Board Specification

Thickness
1.2 mm

Rated Operation Voltage
230/415V AC

Current Rating
63A, 100A

Components
Copper/Aluminum busbar, neutral & earth link, interlocking latches

Cooling System
Natural air ventilation

Rated Current
63A - 100A

Panel Type
Surface/Flush Mounted

Protection Class
Class I

Control System
Manual operation (MCB, MCCB compatible)

Protection Level
IP42

Features
Double door for additional safety, modular design, rust resistant, concealed hinges

Cabinet Material
CRCA (Cold Rolled Close Annealed) Steel

Base Material
Mild Steel

Connectivity Type
Fixed wiring

Way
8, 12, 16, 18, 24 way (varies by model)

Operating Voltage
230/415V AC

Rated Insulation Voltage
660V

Cover Material
Powder coated steel with clear/opaque acrylic window

Product Type
Distribution Box

Material
Mild Steel

Surface Finish
Powder coated, anti-corrosive

Standard
IS 8623, IEC 60439

Surface Color
White

Rated Voltage
230V/415V AC

Frequency (MHz)
50/60 Hz

Maximum Output Current
100A

Dimension (L*W*H)
Varies by model (typ. 400 x 350 x 110 mm)

Warranty
Yes

Application
Residential, commercial and industrial electrical distribution

IP Rating
IP42 / IP43

Window Type
Transparent polycarbonate/opaque window

Door Handles
Ergonomic chrome plated handle with locking facility

Locking Provision
Yes, provided with lock and key

Mounting Type
Wall mounting (surface/flush)

Cable Entry
Knockouts at top, bottom, and rear

Operating Temperature Range
-10C to +60C

Phase
Single & Three-phase

Incoming Device Compatibility
Compatible with main MCCB/Isolator

Fire Resistance Rating
Flame retardant enclosure

Earthing Provision
Dual earth terminals

Internal Wiring
Copper busbar with anti-tracking barrier

Design Compliance
RoHS compliant

Double Doors Distribution Board Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash Advance (CA), Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque

Supply Ability
100 Pieces Per Week

Delivery Time
6 Days

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Export Market(s)
Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Asia

Main Domestic Market
All India

About Double Doors Distribution Board

Double Doors Distribution Board

The wide range of Double Doors Distribution Board we offer to clients are sturdy, spacious, aesthetically designed to suit all types of MCB's. These units are fabricated from the best quality CRCA Steel Sheets for good strength and finish. The distribution Boards are supplied duly fitted with Busbar, Din-Channel and Neutral link. We paint these boxes with latest powder coating technology that ensure superior quality finish and also provide protection against corrosive atmosphere.

SPN double door

6 way SPN 160x253x80
8 way SPN 192x253x80
10 way SPN 230x253x80
12 way SPN 260x253x80
16 way SPN 335x253x80

Superior Safety and Versatility

This distribution board is meticulously engineered for enhanced safety with a flame retardant enclosure, locking provision, and IP42/IP43 protection. Ergonomic chrome-plated handles, concealed hinges, and a dual earth terminal streamline daily operation while supporting both main MCCB and isolator devices. Suitable for single and three-phase systems, it adapts effortlessly to varied power distribution scenarios.

Durable Construction and Design Compliance

Made from powder-coated mild steel, the cabinet is both rust-resistant and anti-corrosive. The clear or opaque window, along with concealed hinges, assures user-friendly access and reliable monitoring. Compliance with IS 8623, IEC 60439, and RoHS requirements underlines its focus on safety and environmental standards.

Flexible Installation and Applications

With knockouts at the top, bottom, and rear, the board facilitates flexible cable routing. Wall mounting (surface or flush) and variable dimension models ease integration into residential, commercial, or industrial spaces. It caters to different requirements with available ways from 8 to 24, and supports manual operations of MCBs or MCCBs.

FAQ's of Double Doors Distribution Board:

Q: How is the Double Doors Distribution Board installed?

A: This distribution board is designed for wall mounting and supports both surface and flush installation, making it adaptable to a variety of architectural layouts. The available knockouts at the top, bottom, and rear allow flexible cable entry and simplify the mounting process.

Q: What safety benefits does the lockable double door provide?

A: The lockable double door, complemented by an ergonomic chrome-plated handle and key, enhances operational safety by restricting unauthorized access. This feature is especially valuable in shared or high-traffic environments, reducing the risk of tampering or electrical hazards.

Q: When should a transparent polycarbonate window be selected over an opaque window?

A: A transparent window is recommended when visual inspection of internal components without opening the cabinet is desired. This is beneficial in environments where routine checks are essential. An opaque window offers privacy and is suited for locations where internal visibility is less critical.

Q: Where can the distribution board be used?

A: It is versatile for use in residential, commercial, and industrial installations. Its IP42/IP43 protection rating and rugged construction make it suitable for a wide range of electrical distribution applications across these sectors.

Q: What process ensures the enclosure's resistance to corrosion and fire?

A: The cabinet is constructed from 1.2mm thick CRCA mild steel and finished with a powder-coated, anti-corrosive surface. The enclosure is also flame retardant, ensuring safety and durability in demanding environments.

Q: How does the internal wiring design enhance electrical safety?

A: The use of copper busbars with an anti-tracking barrier reduces the risk of electrical faults and increases operational safety by preventing short circuits and insulating critical areas within the board.

Q: What are the main benefits of using this distribution board?

A: Key benefits include robust protection against environmental and operational hazards, compatibility with a range of main MCCB/Isolator devices, flexible installation options, multiple cable entry points, comprehensive earthing provision, and compliance with international electrical safety standards.
